Model :E23L
|
LCD |
/23.6/27 inch LED Backlight,1920×1080 Full HD |
|
Processors |
/i7/i5/i3 Support Intel for 12th/11th/10th/9th/8th/7th/6th/5th/4th/3th/2th Generation |
|
|
/i7/i5/i3/Pentium/Celeron Up to 65W Desktop Processors |
|
Motherboard |
For Intel H610/H510/ /H110/H81/H61/HM76/HM65/HM55/N5095/J4125 Thin Mini ITX |
|
Hard Disk |
"M-SATA SSD or 2.5'' HDD |
|
GPU |
for lntel HD Graphics |
|
Memory |
2x DDR4 SO-DIMM 2400GHz, 32G Memery |
|
|
or 2x DDR3 SO-DIMM 1600GHz, 16G Memery |
|
Storge |
Support 1x SSD/HDD 1x M-SATA/M.2 SSD Slot |
|
Network Connections |
Realtek /lntel b/g/n/ac M.2 WIFI Module |
|
|
Blutoo4.0/5.0/6.0, 10/100/1000M Ethernet Network |
|
OPTANE Speaker |
Support 1x Intel OPTANE Slot(B360 Optional) |
|
|
Built-in 2x 3W stereo speakers |
|
Rear Port |
1*(12V/7A or 19V/6A)DC Jack 1*HDMI Port |
|
|
1 *VGA Port 2* USB 3.0/2* USB 2.0 |
|
|
1* Headphone Jack 1 *Micphone Jack |
|
OS |
For Windows 10 orWIN11 |
|
Power Adaptor |
1x90w/120W Power adaptor outside |
|
|
or 1x 15oW Power supply inside |
|
Side Port |
2*USB 3.0/2*USB 2.0 |
|
Camera |
YES |
|
Fan |
YES |
|
WIFI |
802.11 b/g/n 2.4G/5G/BT4.0 |
|
Power Supply |
12V/7A or 19V/7.89A |
