| System |
CPU |
|
|
|
RK3128 Quad core cortex A7(Rk3288 Optional) |
|
|
|
|
|
|
|
|
| RAM |
|
|
|
1GB(2GB,4Gb Optional) |
|
|
|
|
|
|
|
|
| Internal memory |
|
|
|
16GB(32GB 64GB Optional) |
|
|
|
|
|
|
|
|
| Operation system |
|
|
|
Android 6.0(8.1 Optional) |
|
|
|
|
|
|
|
|
| |
|
Touch screen |
|
|
|
10-Point capacitive touch G+G |
|
|
|
|
|
|
|
|
| Display |
Panel |
|
|
|
10.1"LCD IPS panel |
|
|
|
|
|
|
|
|
| Resolution |
|
|
|
1280*800 |
|
|
|
|
|
|
|
|
| Display mode |
|
|
|
Normally black |
|
|
|
|
|
|
|
|
| Viewing angle |
|
|
|
85/85/85/85 (L/R/U/D) |
|
|
|
|
|
|
|
|
| Contrast ratio |
|
|
|
800 |
|
|
|
|
|
|
|
|
| Luminance |
|
|
|
250cd/m2 |
|
|
|
|
|
|
|
|
| Aspect Ratio |
|
|
|
16:10 |
|
|
|
|
|
|
|
|
| Network |
WiFi |
|
|
|
802.11b/g/n |
|
|
|
|
|
|
|
|
| Ethernet |
|
|
|
RJ45,10M/100M |
|
|
|
|
|
|
|
|
| Buletooth |
|
|
|
Bluetooth 4.0 |
|
|
|
|
|
|
|
|
| Interface |
Card slot |
|
|
|
TF,Support up to 32GB |
|
|
|
|
|
|
|
|
| USB |
|
|
|
USB slave |
|
|
|
|
|
|
|
|
| USB Host |
|
|
|
USB host *2 |
|
|
|
|
|
|
|
|
| HDMI |
|
|
|
HDMI output |
|
|
|
|
|
|
|
|
| Power jack |
|
|
|
DC power input |
|
|
|
|
|
|
|
|
| Earphone |
|
|
|
3.5mm earphone+micphone |
|
|
|
|
|
|
|
|
| USB |
|
|
|
USB for serial (RS232 format) |
|
|
|
|
|
|
|
|
| RJ45 |
|
|
|
Ethernet interface ( POE function optional IEEE802.3at,POE+,class 4， 25.5W ) |
|
|
|
|
|
|
|
|
| Media play |
Video format |
|
|
|
MPEG-1,MPEG-2,MPEG-4,H.265,H.264,VC-1,VP8, etc.,support up to 1080p |
|
|
|
|
|
|
|
|
| Audio format |
|
|
|
MP3/WMA/AAC etc. |
|
|
|
|
|
|
|
|
| Photo |
|
|
|
jpeg |
|
|
|
|
|
|
|
|
| Other |
NFC |
|
|
|
Optional ,NFC 13.56MHz，ISO14443A/ISO14443B/ISO 15693/Mifare classic/Sony felica |
|
|
|
|
|
|
|
|
| Microphone |
|
|
|
Standard single microphone |
|
|
|
|
|
|
|
|
| Speaker |
|
|
|
2*1W |
|
|
|
|
|
|
|
|
| Camera |
|
|
|
2.0M/P,front camera |
|
|
|
|
|
|
|
|
| Language |
|
|
|
Multi-language |
|
|
|
|
|
|
|
|
| Working temp |
|
|
|
0--40degree |
|
|
|
|
|
|
|
|
| Certificates |
|
|
|
|
|
|
|
|
|
|
|
|
| Color |
|
|
|
White/black |
|
|
|
|
|
|
|
|
| Accessories |
Adapter |
|
|
|
Adapter,12V/1.5A |
|
|
|
|
|
|
|
|
| User manual |
|
|
|
yes |
|
|
|
|
|
|
|
|
