Model :TK-E198
Form Factor | Aluminium alloy |
Dimensions | 360*232*20.5mm |
Weight | about 2KG |
Color | Metallic grey |
Screen Size | 15.6" |
Screen Resolution | 1920*1080 ,IPS |
HID-I2C | TRUE |
FT9369 | TRUE |
Type | Rechargeable Lithium-ion polymer battery 11.55V |
Capacity | 5000mAh/57.75Wh |
Working Time | 5Hrs(Max. Brightness) |
Type | 9th/10th Gen Intel® Core i7-9750H/i9-9880H/i5-10200H/i5-10500H/i7-10750H/i9-10885H... |
Speed | Maximum turbo frequency: 4.5GHz-5.3GHz |
Type | Intel® UHD Graphics: 350MHz-1150MHz |
Capacity | SODIMM*2 Maximum Support 64GB(Optional) |
Front | 1M |
Rear | / |
Built-in | Stereo Speakers 8Ω/1.0W |
Built-in | One Analog Microphone |
Built-in | TRUE |
WIFI | M.2 (2230) AC7265 - Support 802.11B/G/N&AC(Optional) |
Bluetooth version | BT 4.2 |
RJ45 | 1000Mbps |
SSD | M.2(2280) Support PCIe Gen3&SATA3.0 |
Data Storage | / |
Support Data Transfer | USB3.0*1 & USB2.0*2 |
USB-C | For Charging*1; For Data Transfer&DP Output*1 |
Music Output | ∮ 3.5mm standard headphone jack |
Video Output | HDMI 1.4 |
Input Device | Backlit Keyboard |
Power supply | 19V4.74A |
Extended external storage | / |
Standard Configuration | TypeC Interface |
Inputting | 100-240V~2A 50/60HZ |
Output | 19V4.74A |
Windows | Windows 10/Windows 11 |
